• High Power Capacity :This DC-DC Buck Boost Voltage Converter Power Module boasts a high power capacity of 4A, ensuring efficient energy supply for your devices.
• Adjustable Switch Module :The product features an adjustable switch module with a frequency of 400KHz, allowing you to control and modify the voltage as per your needs.
• Versatile Voltage Conversion :With a range of 3.8-30V to 1.25-35V, this power supply can effectively convert various voltages, making it a versatile choice for various devices.
• Durable Design :Originating from Mainland China, this brand-branded product is designed with durability in mind, ensuring long-lasting performance and reliability.
• Compact Size :Its compact size makes it easy to install and integrate into your device, saving space while delivering top-notch performance.
• Ideal for Motor Protection :This power module also serves as an ideal motor protector, safeguarding your devices from potential overload or short-circuits.
3Pcs XL6009 DC-DC Buck Boost Voltage Converter Power Module 4A 400KHz Adjustable Switch Module 3.8-30V to 1.25-35V Power Supply Module for Solar Panel
Features:
• Super material: It is made of electronic accessories, nickel plating on surface(anti-oxidatioan), inner conductor: pure copper. It is long lasting and durable for you to use.
• Package including: 10 Pack of XL6009 DC module, which consist of high-precision potentiometer (clockwise boost, counterclockwise buck), high frequency filter capacitor and power indicator.
• Input and output: Input range: 3.8V ~ 32V.Output range: 1.25V ~ 35V.Input current: 3A (maximum), no-load 18mA (5V input, 8V output, no-load less than 18mA. The higher the voltage, the larger the no-load current.).Conversion efficiency: <94% (the greater the pressure difference, the lower the efficiency).Switching frequency: 400KHz. Output ripple: 50mV (higher voltage, larger current, larger ripple)
• Feature: High efficiency and low ripple with power indicator. In addition to the current limiting and voltage regulation step-down function. High reliability, strong vibration resistance, good electromechanical performance.
• A wide range of applications: This module can be applied to the buck field where the input voltage is higher than the output voltage, such as battery, power transformer, DIY adjustable power supply, and so on. Maintain stable output voltage and limit the output current over a range of input voltages. Used forbooster voltage stabilizer power supply, DIY adjustable mobile power supply, booster charger.
Specifications
Automotive voltage stabilization, solar photovoltaic power generation, wind power generation and other unstable applications.
Technical Parameters:
Module nature: non-isolated boost (BOOST)
Rectification method: asynchronous rectification
Input range: 3.8V ~ 32V
Output range: 1.25V ~ 35V
Input current: 3A (maximum), no-load 18mA (5V input, 8V output, no-load less than 18mA. The higher the voltage, the larger the no-load current.)
Conversion efficiency: <94% (the greater the pressure difference, the lower the efficiency) Switching frequency: 400KHz
Output ripple: 50mV (higher voltage, larger current, larger ripple)
Working temperature: -40 ℃ ~ + 85 ℃
Dimensions: 48mm x 25mm x 14mm.
Package:
3Pcs XL6009 DC-DC Buck Boost Voltage Converter
1. Key away from Fire
2. Due to includeing small parts, please keep away from Children under Three.
3. Please leave 5 star feedback if you’re satisfied with our products and service, we will appreciate it
4. If the products you received was damaged or any more question, please feel free to contact us.
